At Astromet Steels, we understand the important feature pipes play in several industries. When it involves electricity, reliability, and versatility in immoderate-temperature applications, appearance no in addition than ASTM A106 seamless pipe. We are a leading ASTM A106 Grade B pipe exporter imparting a considerable inventory, exceptionally excellent, and unmatched customer support.
ASTM A53 GRADE B PIPE SPECIFICATIONS
| Carbon Steel Seamless Pipe Dimensions | ASTM A53 Grade B, ASME SA53 and API |
| Api 5l Carbon Steel Pipe Size | 1/2 NB to 36 NB |
| Api 5l Carbon Steel Seamless Pipe Thickness | 3-12mm |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| High Carbon Steel Tube Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| Type | Seamless / ERW / Welded / Fabricated |
| Form | Round, Hydraulic Etc |
| Carbon Steel Tube Material Length | Min 3 Meters, Max18 Meters, or according to customer’s requirement |
| Jis Carbon Steel Pipe End | Plain End, Beveled End, Treaded |
| Specialized in | Large Diameter Carbon Steel Pipe, seamless carbon steel pipe, carbon steel pipe suppliers, carbon steel seamless pipe suppliers, carbon steel erw pipe suppliers, carbon steel welded pipe suppliers, Api 5l Carbon Steel Seamless Pipe |
Unveiling the Strength of ASTM A106 Seamless Pipe:
ASTM A106 seamless pipe, additionally known as ASTM A106 GR. B carbon steel pipe, is specifically designed for excessive-temperature providers. This pipe grade is famous due to its:
- Exceptional Strength: It can withstand excessive pressures and temperatures, making it suitable for worrying packages.
- Superior Weldability: provides tremendous weldability, simplifying fabrication methods.
- Versatility: Available in an extensive variety of sizes and thicknesses, those pipes can accommodate numerous undertaking requirements.
ASTM A106 GRADE B PIPE SPECIFICATIONS
| Standards | ASTM, ASME and API, ANSI B 36.10 |
| Craft | Cold rolled and Cold drawn |
| ANSI Standard | B1.20. |
| Grades | ASTM A106 Grade A, Grade B, Grade C |
| Type | ERW / Seamless / Fabricated / Welded |
| Size | 1/2” NB to 36” NB |
| Length | Minimum 3 Meters, Maximum 18 Meters |
| Thickness | 3-12mm |
| Specialized in | Large Diameter ASTM A106 Grade B Pipe |
| Schedules | Schedule 20, 30, 40, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH & heavier |
| ASME Standard | B36.10M |
| Tolerance |
Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| End | Plain End, Beveled End, Treaded |
ASTM A106 GRADE B PIPE MANUFACTURING PROCESS
- The Rolling and Welding Stage
- Cleaning and Warming Stage
- The rolled Carbon steel pipes thus manufactured are cut to the required lengths depending upon the industrial demand.
- Cold-Drawing Stage
- The Finishing Process
ASTM A106 GRADE B PIPE EQUIVALENT MATERIAL
| Former | New | |||
| Execution | Standard | Material | Standard | Material |
| Seamless | ASTM A106 | GRADE B | EN 10216-2 | P265GH |
| Seamless | ASTM A333 | GRADE 6 | EN 10216-4 | P265NL |
| Welded | API 5L | Grade B | EN 10208-2 | L245NB |
| Welded | API 5L | Grade X52 | EN 10208-2 | L360NB |
| Seamless | API 5L | Grade B | EN 10208-2 | L245NB |
| Seamless | API 5L | Grade X52 | EN 10208-2 | L360NB |
CARBOR STEEL ASTM A106 GRADE B PIPE CHEMICAL COMPOSITION
| Standard | Grade | Process | Chemical Composition % | |||||||||
| C max | Mn* | P max | S max | Si min | Cr˟ max | Cu˟ max | Ni˟ max | Mo˟ max | V˟ max | |||
| ASTM A106-15 | B | SMLS | 0.30* | 0.29-1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.40 | 0.15 | 0.08 |
| ASTM A106-15 | C | SMLS | 0.35* | 0.29-1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.40 | 0.15 | 0.08 |
| ASTM A53-12 | B | SMLS | 0.30* | 1.20 | 0.05 | 0.045 | — | 0.40 | 0.40 | 0.40 | 0.15 | 0.08 |
ASTM A106 GRADE B PIPE MECHANICAL PROPERTIES
| ASTM A106 Grade A | ASTM A106 Grade B | ASTM A106 Grade C | ||
| ASTM A106 | Tenside strength, min, psi (MPa) | 48000(330) | 60000(415) | 70000(485) |
| Yield strength, min, psi (MPa) | 30000(205) | 35000(240) | 40000(275) | |
TYPES OF CARBON STEEL SA 210 GRADE A1
SA 210 GRADE A1 PIPE SEAMLESS PIPE
SA 210 GRADE A1 PIPE WELDED PIPE
SA 210 GRADE A1 PIPE ERW PIPE
SA 210 GRADE A1 PIPE EFW PIPE
Applications for ASTM A106 Seamless Pipe:
The first-rate houses of ASTM A106 pipes make them a preferred preference throughout numerous applications, along with:
- Power Plants: Used in boiler tubes, superheater tubes, and different high-temperature piping systems.
- Refineries and Petrochemical Plants: Conveying warm fluids and gasses inside these facilities.
- High-Pressure Pipelines: Suitable for transporting fluids and gasses over long distances at multiplied temperatures.
- Structural Applications: In fantastic cases, ASTM A106 pipes can be used for structural functions due to their power.
Equivalence to ASTM A53 Grade B Pipes:
It’s critical to be aware that ASTM A106 Grade B pipes are considered equal to A53 Grade B carbon steel pipe (ASTM A53 GR B) in phrases of chemical composition and mechanical homes. However, A106 offers extra blessings like advanced weldability and is in particular designed for excessive-temperature packages.
Astromet Steels: Your Trusted
As a major A53 GR B carbon metallic pipe exporter, Astromet Steels gives a worldwide obtain, making sure we can supply your pipes anywhere you’re placed. We are committed to presenting great issuer and top-extremely good products to meet your undertaking desires.
Ready to Get Started with Your ASTM A106 Pipe Requirements?
Contact Astromet Steels these days to talk approximately your assignment necessities for ASTM A106 seamless pipe. Our crew of experts will manual you through the selection way, making sure you acquire the best pipes in your immoderate-temperature applications.
